Manual Setting - Concept SO4000 Manual De Instrucciones

EN
DRYING VEGETABLE (program without infrared light)
Turn the button to the vegetable icon . The dedicated icon will light up. Press the button and the dryer
will start operating automatically. The pre-set temperature of 60 °C and time of 6 hours will be displayed on
the screen. A green HEATER indicator will light up. (green back lightning means drying without use of the
infrared light).
If you want to select another program, turn the button to the desired position. The dedicated icon will light
up. Press the control button inward to confirm your selection. The dryer will now start operating in the
newly selected program. If you just turn the button and do not confirm the newly selected program within
10 seconds, the previous selected program will continue. When the program has finished and the time has
elapsed, the appliance automatically switches to KEEP WARM mode for 24 hours unless it is not turned off.
This temperature is lower than the temperature of the program. The screen will light up green. After 24 hours
the dryer switches off automatically.
MAKING YOGHURT (program without infrared light)
Turn the button to the yoghurt icon The dedicated icon will light up. Press the button and the dryer
will start operating automatically. The pre-set temperature of 42 °C and time of 8 hours will be displayed on
the screen. A green HEATER indicator will light up. (green back lightning means the program does not use of
the infrared light).
For making yoghurt you can use both plastic and glass containers with a lid.
RECIPE FOR HOME-MADE YOGHURT
What you will need:
Pasteurized whole milk (the less fat in milk, the more watery the yoghurt will be) - 1 l
(if you have milk from the farm, it is necessary to pasteurize it: bring milk to heat up to 72 °C for 30 seconds,
then cool it to 40 °C)
Yoghurt - 3 to 4 tablespoons of high-quality yoghurt of a room temperature containing live cultures (e.g.
Choceňský or Hollandia) or powder of yoghurt culture.
Steps:
Mix milk with yoghurt, put the mixture into sterilized glasses, close them with lids with holes and put them in
the dryer. Close the glasses with lids in a way the air can comes in.
Select the yoghurt making program. Do not mix during the fermentation process!
After the program is done, let yoghurt cool down in a fridge.
When using a powder of yoghurt culture, first bring milk to heat of 42-45 °C, add the powder and stir until it
dissolves completely. Then pour the mixture into the glasses, cover with lids and put in the dryer.
Always use clean containers, dishes and properties only, to avoid contamination of the mixture with „bad"
bacteria, that could stop yoghurt from being produced.
46
If you want to select another program, turn the button to the desired position. The dedicated icon will light
up. Press the control button inward to confirm your selection. The dryer will now start operating in the
newly selected program. If you just turn the button and do not confirm the newly selected program within
10 seconds, the previous selected program will continue. When the program has finished and the time has
elapsed, the appliance automatically switches to KEEP WARM mode for 24 hours unless it is not turned off.
This temperature is lower than the temperature of the program. The screen will light up green. After 24 hours
the dryer switches off automatically.
STERILIZATION (cleaning)
After frequent or long-term use, the dryer may emit a mild odour and it should be cleaned. Turn the button to
the sterilization icon . The appliance will start operating. The pre-set temperature of 85 °C and time of 1 hours
will be displayed on the screen. After the program is done, the dryer switches off automatically.
OPTIONAL PROGRAMS - These programs can be set as needed.

MANUAL SETTING

Turn the button to the sterilization icon
enter the temperature setting. Turn the control button to select a temperature from 35 to 75 °C. After the
temperature is selected, push the control button inwards to confirm it. You can now set the operating time
from 1 to 99 hours. Turn the control button to the desired value and press it to confirm.
You can also decide whether to dry with the infrared light or not: to conform the set time, turn the control
button to the infrared
the set time, the infrared light will be on. If you want to dry without the infrared light, turn the button to the
Heater icon and press to confirm. The unit will start operating at the selected temperature and for the
set time, the infrared light will be off. During the operation, the program can be adjusted at any time.
Magnetic closing:
When you open the dryer door, the back lightning goes off. The temperature indicator will show the F1 sym-
bol. Time is lit up. If the door is closed within 5 minutes, the unit will continue the selected program.
If the door is left open for more than 5 minutes, the appliance switches off.
Switching off the appliance:
Press and hold the control button to switch the appliance off. All the indicators will go out slowly.
Error Messages:
F1: The door is open
F2: The temperature exceeded the allowed limit, as soon as the appliance cools down, it will continue
operating.
SO4000 SO4000
. The dedicated icon will light up. Press the control button to
icon and press. The unit will start operating at the selected temperature and for
EN
47
