IV. Product Features
• Built in water bottle warmer maintains water at up to 37°C with an allowable tolerance of ± 3°C
• "Prime" feature runs pump for 20 seconds with automatic timer
• Includes side water bottle clip for traditional water bottle holder
• Safety feature prevents pump from running when pump head is open
• Robust motor design for consistent performance
• Water bottle holder is angled for easier access to water bottle and tubing

Theory Of Operation

The ENDO STRATUS® irrigation pump works by turning a peristaltic-roller-type pump head to move
liquid through a tube set and into a GI endoscope system. The pump head will not operate if the pump
head is open, and will cease to operate if the pump head is opened while the motor is activated.
The unit incorporates a "prime" feature which allows the unit to operate for a pre-set period of time. This
feature can be canceled while in progress by pressing the foot pedal.
The water bottle warmer is intended to maintain the warmth of the water in a sterile water bottle that has
been pre-warmed. It is controlled by dual temperature sensors for redundancy and safety. There is a heating
element integrated into the water bottle holder which then radiates heat through the bottle and into the
water. The temperature of the water bottle holder is maintained at a maximum of 37°C ± 3°C.
V. Technical Specifications
Electrical Specifications
Input Voltage:
Input Frequency:
Power Consumption:
Fuse Rating:
Certifications:
Classification:
Water Bottle Warmer:
IP Rating (Ingress Protection):
WARNING:
Grounding reliability can only be achieved when connected to a receptacle marked "Hospital Grade".
IFU-51 / REV G
100-240 VAC
50-60 Hz
110 VA
M10AL250V
Medium acting, 10 amp, low breaking capacity, 250 volt
Replace fuses only with those of same type and rating
IEC-60601-1, IEC-60601-1-2, IEC-60601-2-18
Class 1 Type B
20W resistive element with dual temperature sensors.
IP24
EN - 6
