EN
Replacing the
Fuse
DMX Linking
DMX Connection
Master/Slave
Connection
Mounting
Product
Mounting
Diagram
All manuals and user guides at all-guides.com
1.
Disconnect this product from power.
2.
Using a Flat head screwdriver, unscrew the fuse holder cap from the
housing.
3.
Remove blown fuse and replace with a good fuse of the same type
and rating.
4.
Screw the fuse holder cap back in place and reconnect power.
The STRIKE 324 will work with a DMX controller using a regular DMX serial
connection. A DMX Primer is available from www.chauvetpro.com.
The STRIKE 324 uses a regular DMX data connection for its DMX
personalities: 1 Ch, 5 Ch, 8 Ch, and 12 Ch. See the User Manual to connect
and configure for DMX operation.
The STRIKE 324 uses the DMX data connection for its Master/Slave mode.
See the User Manual to connect and configure for master/slave operation.
Overhead Mounting
Clamp
(Model #CLP-15)
Safety Cable
(Model #CH-05)
Secure the safety cable using
the passageway on the back
of the product.
3
STRIKE 324 QRG
Floor Mounting
