Performance Tests and Calibration
Table 6-2
Performance verification tests (continued)
Test function
[b]
DC current
AC current
[c]
AC + DC current
Peak current (max)
[a] Only available in U1212A and U1213A.
Set both calibrator and multimeter to internal reference.
To perform the measurement, connect the K-type thermocouple extension (with miniature thermocouple connector on both ends) between
the calibrator's TC output and multimeter via a TC-to-banana adapter
Allow at least 1 hour for the multimeter to stabilize before measurements are taken.
The error limit does not include the error contributed by the thermocouple extension. To eliminate the thermocouple error, compensation of
the calibrator output through a reference thermometer is recommended.
Ensure that the ambient temperature is stable within ± 1°C. Make sure that the multimeter is placed in a controlled environment for at least 1
hour. Keep the multimeter away from any ventilation exit. Do not touch the thermocouple test lead after connecting it to the calibrator. Allow
the connection to stabilize for at least another 15 minutes before performing the measurement.
92
Range
5520A output
use with
5500A/COIL
40 A
0.8 A
400 A
8 A
1000 A
20 A
40 A
0.8 A, 45 Hz
0.8 A, 100 Hz
0.8 A, 400 Hz
400 A
8 A, 45 Hz
0.4 A, 400 Hz
1000 A
14 A, 45 Hz
2.99999 A,
400 Hz
20 A, 45 Hz
40 A
0.8 A, 400 Hz
400 A
0.4 A, 400 Hz
1000 A
1 A, 400 Hz
400 A
8 A
peak
60 Hz
Keysight U1211A, U1212A, and U1213A User's and Service Guide
Reference
values
40 A
400 A
1000 A
40 A, 45 Hz
40 A, 100 Hz
40 A, 400 Hz
400 A, 45 Hz
20 A, 400 Hz
700 A, 45 Hz
150 A, 400 Hz
1000 A, 45 Hz
40 A, 400 Hz
20 A, 400 Hz
50 A, 400 Hz
,
400 A
,
peak
60 Hz
Error limits (from nominal 1 year)
U1211A
U1212A
–
±0.75 A
–
±6.3 A
–
±25 A
±0.5 A
±0.9 A
±0.5 A
±1.3 A
±0.5 A
±2.7 A
±4.5 A
±8.5 A
±0.7 A
±1.8 A
±12 A
±22.5 A
—
±14.75 A
–
±30 A
–
–
–
–
–
–
±12.3 A
±12.3 A
U1213A
±0.75 A
±6.3 A
±25 A
±0.9 A
±1.3 A
±2.7 A
±8.5 A
±1.8 A
±19 A
±14.75 A
±25 A
±3.45 A
±2.5 A
±13.25 A
±12.3 A
