3. Turn the bypass valves 45° clockwise to the
BYPASS position.
4. To engage the drive system, turn the bypass valves
to the RUN position.
To set the cutting deck in transport
position or mow position
The cutting deck must be in transport position during
transportation.
• Push the deck lift pedal and the deck release pedal
forward to unlock the deck lift.
• Push the deck lift pedal forward until the cutting deck
latches in the transport position.
• Push the deck release pedal forward to lower the
cutting deck into mow position.
To set the cutting height
1. Set the cutting deck in transport position. Refer to
To set the cutting deck in transport position or mow
position on page 13 .
2173 - 002 - 22.08.2023
2. Push in the button on the top of the pin and pull the
pin out.
3. Put the pin in the hole for the correct cutting height.
Note:
If you mow on 2 in./5.1 cm or lower,
examine if it is necessary to adjust the deck lift
To adjust the deck lift springs on
springs. Refer to
page 13 .
4. Push the release pedal forward to release the
transport latch and lower the cutting deck into mow
position.
To adjust the deck lift springs
Examine if it is necessary to adjust the deck lift springs if
you mow 2 in./5.1 cm or lower.
1. Tilt the seat forward.
2. Loosen the nut to adjust the spring tension.

To start the engine

1. Sit on the seat.
2. Push the PTO button to disengage the drive on the
cutting deck.
13
