Standard mounting brackets
®
The HEATSTRIP Enhance with remote and app control comes with a pair of standard mounting brackets. These adjusta-
ble brackets allow direct ceiling or wall mount, and come with pre-set angle options of parallel, 22.5° and 45°.
The flexible standard mounting bracket can be turned 90 degrees to mount onto a beam, it can also be used to suspend
with chains.
The brackets need to be mounted onto a secure frame or wall with a minimum distance between the two brackets. The
minimum distance ("B") for each model is listed on the next page. All dimensions shown below are in (mm).
When completing the installation, ensure all screws are tight and unit is secure.
Note: When suspension mounting, chains are not included.
PACKAGED
WEIGHT
PART No MATERIALS COLOUR
(kg)
DIMENSIONS (mm)
ANODISED
ZBRAK-156 125 x 150 x 40 0.2 BLACK
ALLOY
