Exhaust circuit extractor.

Ceramic fiber joint (replace).

Exhaust circuit extractor.

Ceramic fiber joint (replace).
6.6. Dismantling and cleaning of gas outlet pipes.
When mounting the gas outlet pipeline, make sure it is well assembled, preferably sealed with silicone. If the
pipe has sealing joints, you must verify its good condition and replace it if necessary.
6.7. Empty the hopper to take remaining pellets out to avoid pellets absorb humidity.
6.8. Review the fireplace door joints.
Review in detail any imperfections which may cause an air inlet. Replace them if necessary.
6.9. Cleaning of dirt which may be accumulated on the inside of the boiler (lower part, components, etc.). You
can access to it by the rear of thereof.
6.10. Cleaning of the pellets drop tube.
Use the brush provided by ECOFOREST to remove the dust until the end of the tube.
6.11. To ensure the proper operation of the safety valve, it must be discharged at the end of each season or once a
year. To manipulate the discharge tab, the rear grille should be removed from the boiler. Once you have
access to the tab, lift it and check that discharge occurs. Warning: The discharge valve must be connected to
a drain trap and the water passage must be visible.

Security valve.

Discharge tab.
57
Drawing 27
Drawing 28
Drawing 29
