Figura D-7: Menú Configuración manual
Characterize
1 Sensor Type
1
2 Sensor Tag Parameters
Measurements
1 Flow
2 Density
3 Temperature
4 Update Rate
2
5 Set Up Special Units
6 Set Up External Compensation
7 Set Up GSV
Display
1 Language
2 Display Variable Menu Features
3
3 Offline Variable Menu Features
4 Backlight
5 Set Up Display Variables
6 Set Up Decimal Places
Manual de configuración y uso
On-Line Menu >
2 Configure >
1 Manual Setup
Inputs/Outputs
1 Set Up Channels
2 Set Up mA Output
4
3 Set Up Frequency Output
4 Set Up Discrete Output
5 Map Variables
Info Parameters
5
1 Transmitter Info
2 Sensor Information
Communications
1 HART Address
2 Tag
6
3 Device Identification
4 Dev ID (CP)
5 Set Up Burst Mode
Uso del Field Communicator con el transmisor
Transmitter Info
1 Tag
2 Xmtr Serial Num
1 3 Message
4 Descriptor
5 Date
6 Write Protect
Sensor Information
1 Sensor Type
2 Sensor Serial Num
2
3 Tube Wetted Mat.
4 Tube Lining
5 Sensor Flange
257
