R E P L A C E M E N T
P A R T S L I S T
Reference
Number
Description
41
Ring Gear Bearing
42
Carrier Bushing
43
Planet Carrier Assembly
44
Gearbox Bushing
45
Plastic Closure
46
8/32 x 3/8 Pan Head Screw
47
Not applicable this model
48
Not applicable this model
49
Fixed Ring Gear
50
Lock Pin
51
Gearbox Housing (w/ 52, 56–58, 60
specify model no. when ordering)
52
Warning/Clutch Operation Label
(specify model no.)
53
1/4-20 x 5/8 Self Tapping Hex Head Screw
54
Clutch Lever
55
#8 Int. Tooth Lock Washer
56
Dust Cover
57
Plug
58
Rubber Washer
59
Clutch Spring
60
Push-On Retainer
61
2 AWG x 16" Lead Wire Assembly (yellow)
62
2 AWG x 13" Lead Wire Assembly (blue)
63
2 AWG x 10" Lead Wire Assembly (white)
64
10 AWG x 24" Lead Wire Assembly
65
2 AWG x 8' Lead Wire Assembly (black)
66
2 AWG x 8' Lead Wire Assembly (red)
67
2 AWG Boot Terminal
68
Handsaver nylon cord
NS
7" Long Wire Tie
NS
Grease (for one relube)
NS
Motor Brush Repair Kit
ACC
Roller Fairlead
ACC
Pulley Block, 20,000 lbs.
ACC
Circuit Breaker Kit - 12 V
ACC
Circuit Breaker Kit - 24 V
NS
Not Shown
ACC
Accessory
18
Part Number
Qty
90-22607
1
90-10417
1
90-32238
1
90-10418
1
90-23171-05
2
90-23032-17
1
—
—
—
—
90-32233-01
1
90-22252-01
1
90-32256
1
90-22263
1
90-23039-10
4
90-32248
1
90-23048-03
1
90-22103
1
90-23171-07
1
92-10194
2
90-23152-07
1
90-23213-04
2
90-22695-26
1
90-22695-25
1
90-22695-27
1
90-22635-33
1
90-22635-47
1
90-22695-46
1
90-23247-04
3
87-31120
1
94-23058-04
6
90-15020
1
90-10414-05
1
2539
1
7750A
1
2232
1
2232A
1
S O L E N O I D A S S E M B LY
71
70
70
84
71
74
73
78
72
75
Figure 21
79
Reference
Number
Description
70
Remote Switch Pendant (15')
71
Toggle Switch
72
#8-32 x 3/4 Screw
73
Connector Assembly w/ Wires
74
Solenoid Cover (w/ Logo)
75
#8-32 Hex Flanged Nut
77
12VDC Solenoid
24VDC Solenoid
78
Top Bus Bar
79
8-32 x 1/2 Self Tapping Screw
80
5/16-18 Hex Nut
81
5/16 Lock Washer
82
Front Buss Bar w/ Stud
83
Solenoid Bracket
84
10-32 Flange Nut
85
Solenoid Base Plate w/ Studs
86
1/4-20 x 3/4 Hex Head Bolt
87
1/4-20 Hex Flange Nut
88
Solenoid Pack Bracket
89
10-32 x 1/2 Machine Screw
90
Buss Bar #1
91
1/4 External Tooth Lock Washer
NS
X9 Logo
NS
Control Pack, X9 12V (includes 72-85, 89, 90)
NS
Control Pack, X9 24V (includes 72-85, 89, 90)
85
77
84
83
82
81
80
90
86
Part Number
90-33450-01
90-14141
90-23032-22
90-14140
90-32187
90-23149-06
90-20329
90-20331
92-12383
92-23039-01
92-23034-04
92-23057-03
92-12384
94-20118
90-23149-01
90-22627-02
90-23226-10
90-23149-02
90-31027-02
92-23125-01
92-20126
90-23227-02
90-20065
90-32271
90-32272
86
91
88
89
91
87
Qty
1
1
2
1
1
2
2
2
1
4
1
1
1
1
4
1
4
4
1
2
1
2
1
1
1
19
