Parts list

Code Description
1 Front U-frame
2 Rear U-frame
3 Adjustable arm
4 Table frame
5 Pivot arm with position openings
6 Adjustable instep frame
7 Steel Heel Holder Bracket
8R Right Folding Arm
8L Left Folding Arm
9 Bars
10 Hex-head screw
11 Hex-head screw
12 Cross-head screw
13 Washers
14 Cross struts
15 Counternut
16 Counternut
17 Small spring button
18 Large spring button
19 Safety hook
20 Rubber mount
21 Round end cap
22 Foot bar end cap
23 Spring
24 Square end cap
25 Round end cap
26 Guide bush for table frame
27 Washer
28 End cap
29 Bar grip
30 Knob
31 Rubber Heel Holder
32 Nylon strap
33 Nylon strap
34 Strap buckle
35 Nylon lining / table
36 Foam grip
37 Protective cover
38 Hex-head screw
39 Foot rest
40 Hex-head screw
41 Square end cap
42 Spring washer
43 Hex-head screw
44 Length adjustment scale
45 Plastic bushes
46 Foam pad
47 Double-sided adhesive tape
48 End cap
49 Pivot arm ring
AG 02 V4
M8 x 23mm
M6 x 47mm
M6 x 30mm
Ø20*Ø8.5*1.5
M8
M6
(karabiner)
Ø16*Ø6.5*1.0
M8 x 23mm
M8 x 50mm
M8 x 38 mm
Ø27*Ø13.5
