2.1 Device description

8
2
Fig. 2 | TRZ2 turbine gas meter
1 Meter housing
2 Measuring cartridge
3 Index
4 HF pulse generator
(optional)
Please contact your local Honeywell Customer Service Centre for assistance
in commissioning, maintenance and installation of encoders, pulse
generators and volume conversion devices for instance. Repairs may be
carried out only by authorized workshops.
73018696f © Elster GmbH | All rights reserved. Subject to modification
1 7
3
5
4
6
5 LF pulse generator (optional)
6 Pressure test point
7 Temperature test point(s)
8 Oil pump (optional)
