2.1 Device description

Fig. 2 | SM-RI-X turbine gas meter
1 Flow conditioner
2 Meter housing
3 Index
4 HF pulse generator*
* Optional
Please contact your local Honeywell Customer Service Centre for assistance
in commissioning, maintenance and installation of encoders, pulse
generators and volume conversion devices for instance. Repairs may be
carried out only by authorized workshops.
73024521a © Elster GmbH | All rights reserved. Subject to modification
5 Temperature test point*
6 Measuring insert
7 Pressure test point
8 Oil pump*
