Unpacking The Unit

STEP 1 Cut the packing straps and remove box pulling it up, remove corner-post and protective packing, conserve the fiberboard
wing board in a safe place, it will be used later.
Figure 2
STEP 2 Remove decorative plastic return air grille to a safe area away from the unit.
STEP 3 Remove the installation hardware, two gaskets from beneath the unit, and place them in a safe area away from the unit.
Figure 3
STEP 4 Remove the chassis retainer by removing the far right screw in the basepan (see Figure 4); save this screw to reattach the
chassis retainer after installation.
Figure 4
