Poulan Pro PR5020 Manual De Instrucciones

a WARNING! Read and follow all Safety Rules and
Operating Instructions before using this product.
Failure to do so can result in serious injury.
Quick-Start Guide
1
Mix 2.6 oz. of full synthetic 2-Cycle Oil with 1 gallon of gasoline for a
50:1 mixture. Shake well. Pour into fuel tank.
CAUTION: Do not use alternate fuels such as ethanol blends above
10% by volume (E-15, E-85) or any methanol blended fuel.
2
3
4
5
IMPORTANT:
• Never let your saw chain come in contact with soil/dirt during operation. This will completely dull your chain and will
require installation of a new chain.
• Check your chain tension prior to each time you start the chainsaw. Check tension on a new chain after the first 15
minutes of operation. See the manual for chain tensioning instructions.
115817295 Rev. B 2016-05-05
Add bar and chain oil to
oil tank.
Make sure chain brake
is off by pulling back the
handguard.
Slowly press primer bulb
10 times.
Pull blue choke lever out
fully.
Instruction Manual
NOTE: Your product may differ slightly from the
item shown.
6
7
8
9
10
STARTING A WARM ENGINE
4 + 5 + 7 + 8
PR5020
Place right foot in rear
handle as shown. Using
right hand, pull starter rope
sharply 5 times.
Push blue choke lever to
half choke.
Pull starter rope until engine
starts.
Allow engine to warm for 30
seconds. Squeeze throttle
trigger to set normal idle.
Press red switch to STOP
position when finished
using saw.
LDAV50MC
