- regularly clean the drip and discharge, lifting the fan grille if necessary
In order to wash the internal tank of the unit with running water, it is necessary to provide a fixed floor
water discharge when the unit is installed.
Cleaning the sliding closures (
- lift the price holder profile (fig. A)
- lift up and slide out the covers (fig. B)
- proceed to clean, following the procedures for cleaning of external parts
- reattach the covers
- reposition the cover profile
ATTENTION!: If using a water jet cleaner to clean the interior, use a LOW PRESSURE system. Take
special care NOT direct the jet onto painted or plasticised surfaces and keep a mini-
mum distance of 30 cm from the surface to be cleaned (Fig. 3 Rif. 3).

16.Lighting (Fig. 5)

For frontal lighting of the thank, a handrail light can be installed (optional) (Rif. 9).
OPTIONAL: For greater energy savings, the cabinet can be ordered complete with low
consumption LED lighting. This allows for:
- 70% savings on lighting consumption
- reduced refrigerator load
- duration of lights: more than 6 years
- uniform lighting color and intensity on all doors at all times
- improved lighting as temperature decreases.

17.Superstructure (Fig. 10)

The Toronto line of refrigerator units can be provided with a non-refrigerated superstructure with 1 or 2
shelves.
Assemble as follows:
1 - Remove the upper snug cover
2 - Place the superstructure frame in the snug, attaching it with the screws provided
3 - Attach the lower covers (a) using the screws provided
4 - Attach the outlet supports (b) using the screws provided
ATTENTION!: Spread the load uniformly. Do not overload the shelves in a disorderly fashion. The
load must NEVER exceed 90 kg/m
N.B.All these operations should be performed by specialized technical personnel.

18.Disposal of the unit

In conformance with the norms for disposal of waste in individual countries and in respect of the environ-
ment in which we live, we ask you to divide the various parts of the unit so as to allow them to be disposed
of separately or reused. All of the unit parts cannot be disposed of with solid urban waste with the excep-
tion of the metallic parts which generally are not considered special waste for most European countries.
Materials used in construction of the units:
- Iron pipe:
- Copper, aluminum:
- Galvanized sheet metal:
- Polyurethane foam (R134a):
- Tempered glass:
- Wood:
- PVC
- Laminated plastic
N.B.All these operations as for transport and waste processing, should be performed by authori-
sed, specialised personnel only.

19.Helpful advice

It is recommended that the Installation and Use Manual be read carefully, so that the operator, in the case
of malfunction, is able to provide precise information to Technical Assistance by telephone.
Before carrying out any maintenance operation on a refrigeration unit, make sure that the power
00 18/04/2012
Fig. 6)
2
(Fig. 7)
lower frame
refrigeration circuit, electricalsystem, and door frame
base, lower panels, painted panels, base structure
thermal insulation
doors and front glass
foamed tank side frames
Bumpers
sides
