CAUTION:
air to clean the air filter.
7. Put the air filter cartridge in its initial position in the
filter housing. Make sure that the air filter cartridge is
correctly installed on the top of the air intake.
8. Install the air filter cover and make sure that the
particle collector points down.

Electrical system overview

2
1
17
16
1. Display
2. Function button for hydraulic accessories (accessory
for P 520DX)
38
Do not use compressed
7
6
5
4
3
To clean and replace the inlet filter on
the cabin heat
1. Loosen the 2 knobs on the fan system cover and
remove the cover.
2. Pull out the filter holder.
3. Lift out the inlet filter.
4. Carefully clean the inlet filter with a brush.
5. If the inlet filter does not become clean, replace it.
6. Put the inlet filter into the filter holder.
7. Attach the filter holder and tighten the knobs.
8
11
10
9
3. PTO button
4. Ignition key
5. Headlight indicator
12 13 14
15
