Technical Description
14.1.3
Protection class
Version for shaft pegs (2, 3):
Version with hollow shaft (1):
14.1.4
Insulation material class
The motors come up to insulation material class F according to IEC 60085 (UL 1446
class F).
14.1.5
Surface
The motors are coated with polyester powder coating in matt black. This finish is not
resistant against solvents (e.g. trichlorethylene, nitro-thinners, or similar).
14.1.6
Protective device
The standard version of each motor is fitted with an electrically isolated PTC (rated tem-
perature 155°C ± 5%). The PTC does not provide any protection against short, heavy
overloading. Provided that our preassembled Encoder cable is used, the PTC is integra-
ted into the monitoring system of the digital servo amplifiers.
14.1.7
Connection method
The motors are equipped with connectors for the power supply and encoder signals.
Depending on the version, the connectors are allocated to either the side or rear of the
motor, or they can be rotated by 90°.
The mating connectors are not included in the scope of supply. Feedback cables and
power cables are provided pre-assembled.
14.1.8
Feedback
C(H) yyxx-xx-x1xx
High resolution SinCos encoder, single turn, ECN1313 (2048 period), EnDat
C(H) 04xx-xx-x3xx, C(H) 05xx-xx-x3xx und C(H) 06xx-xx-x3xx
High resolution SinCos encoder, single turn, Hengstler ACURO AD36 (2048 period),
BiSS
English - 32
04/2017
IP65 for sealed machine flange
IP64 for sealed machine flange
Servomotors Cartridge DDR
Kollmorgen
