The plate temperature LED (1) flashes intermittently while ironing, thereby indicating
that the selected temperature is maintened.
SUPER-STEAm AND VERTICAL STEAm
Press the super-steam button (4)
penetrate the fabric and remove the most difficult creases.
Wait a few seconds between each pressing action of the iron [Fig. E].
Press the super-steam button (4)
(curtains, hung clothes, etc.) [Fig. F].
The super-steam function can only be used at high temperatures. Stop using super-steam
button (4) when the plate temperature LED (1) goes on and start ironing again when it
goes off.
SPRAY FUNCTION
Verify that there is water in the reservoir (11).
Press the spray button (3) slowly for dense spray or quickly for mist [Fig. G].
Dampen delicate fabric using the spray function or before ironing or alternatively, lay a damp
cloth between the fabric an the iron. Do not use the spray function on silk or synthetics.
EMPTYING PROCESS
Disconnect the plug (13) from the socket.
Open the latch (6).
Empty the reservoir (11) by turning the iron upside down and shaking it lightly.
Let the iron cool down completely.
Always set the iron upright.
NOTE: If the appliance is not to be used for several weeks, wait for the appliance to cool
down compltely before emptying the water reservoir completely, according to the
instructions in the relevant chapter. When the appliance is switched on again, refill the
reservoir as indicated in the relevant chapter.
ZERO-CALC ANTI-SCALE SYSTEm
A special resin filter inside the water reservoir decreases the water hardness and limits the
formation of limescale in the plate. The resin filter is permanent and cannot be replaced.
SELF CLEAN/CALC-CLEAN SYSTEm
The function allows the internal part of the plate to be cleaned from limescale residue or
other impurities.
It is recommended to implement this function every 5 - 10 times it is used.
Fill the water reservoir (11) up to the maximum (MAX) level (9).
Set the steam selector (5) to 0.
Adjust the temperature knob (2) to maximum and wait for the plate temperature control LED
(1) to go off.
Disconnect the plug (13) from the socket and immediately place the iron in a horizontal
position over a wash basin.
to generate a strong shot of steam that is able to
intermittently to iron even in an upright direction

END OF USE

MAINTENANCE
