Setup

Vehicle charging and supply cables

Information on vehicle charging cables
and plugs
Different vehicle charge ports and vehicle plugs
A
are available depending on country-specific vehicle
equipment.
IEC 62196-2/
SAE-J1772-2009
Type 1 UL/IEC
Selecting a Supply Cable
For regular charging with optimum charging speed,
use only the supply cables listed below. The maxi-
mum achievable charging power is up to 22 kW (de-
pending on device variant, power grid/domestic con-
nection and on-board charger). When driving abroad,
always carry the appropriate supply cable for the
country you are visiting with you.
NOTICE
In some countries, only approved supply cables may
be used. When driving abroad, always carry the ap-
propriate supply cable for the country you are visiting
with you.
1. Time of printing. Further information is available from your authorized Porsche dealer or your local electricity supplier.
Country Supply ca-
bles for in-
dustrial
electrical
outlets
B
Argentina 5, 6, 7, 8
Bolivia, Paraguay, 5, 6, 7, 8
Uruguay, Saint
Marteen, Saint
Martin
Chile 5, 6, 7, 8
Peru 5, 6, 7, 8
Country-specific approval of supply cables (exam-
ples)
The vehicle cable can be 8.2 or 24.6 ft. (2.5 or
7.5 meters) long, depending on the situation. The
total length of the supply cable, control unit and vehi-
cle cable is limited in some countries, e.g. to 16.4 ft.
(5 m) in Switzerland and to 24.6 ft. (7.5 m) in Israel
and the USA .
1
Supply ca-
bles for do-
mestic elec-
trical outlets
C
B
D
A
Setup
17
