Power Display LED
When the camera is supplied with power, LED is on.
Video Output Terminal
The monitor video input terminal is connected with this terminal through
which the camera video signal comes out.
Remote Input Terminal(RS-232)
This terminal is used for camera control at the production plant.
All manuals and user guides at all-guides.com
2 3
1
1 TXD
2 RXD
3 +5V
4 GND
