Product Manual Ring Wall STJ
Heater connection
cable H07RN-F/
Effect 60245 IEC 66
mm
400-415V 3N~
4,5 5 x 1,5
6,0 5 x 1,5
8,0 5 x 2,5
Table 2 Connection cable and fuse

3.4 Electric heating toggle

Electric heating toggle applies to homes with an electric heating system.
Sauna heater has connections (marked N - 55) for controlling the electric heating toggle. Connectors N - 55 and the heating
elements are simultaneously live (230V). The sauna heater thermostat also controls the heating toggle. In other words,
home heating turns on once the sauna thermostat cuts power off the sauna heater.
Image 3 Location for the connection box

3.5 Location the connection box for connection cable in the sauna room

A = Specified minimum safety clearance
1. Recommended location for the connection box
2. Silumin box recommended in this area.
3. This area should be avoided. Always use a silumin box.
In other areas, use a heat-resisting box (T 125 °C) and heat-resisting cables (T 170 °C). The connection box
must be clear of obstacles. When installing the connection box to zones 2 or 3, refer to the instructions and reg-
ulations of the local energy supplier.
Fuse Heater connection
cable H07RN-F/
60245 IEC 66
2
A
3 x 10
3 x 10
3 x 16
A
A
Fuse
2
mm
230V 3~ A
4 x 2,5 3 x 16
4 x 2,5 3 x 16
4 x 6 3 x 25
A
A
3.
2.
Heater connection Fuse
cable H07RN-F/
60245 IEC 66
2
mm
230-240V 1N~ / 2~ A
3 x 4,0 1 x 20
3 x 6,0 1 x 35
3 x 6,0 1 x 35
1.
11
