KNOW YOUR SCROLL SAW

1
2
3
14
15
16
17
18
4
5
6
7
20
9
8
19
4
12
13
11
1 - Blade tension knob
2 - Arm housing
3 - Rubber bearing covers
4 - Table
5 - Sawdust blower
6 - Storage area
7 - Base
8 - Bevel scale and pointer
9 - Table/bevel lock knob
10 - Lower blade holder
11 - Blade guard foot
12 - Blade guard root lock knob
13 - LED light
14 - Upper blade holder
15 - Table insert
16 - Sawdust collection port
17 - ON/OFF switch
18 - Speed control knob
19 - Table adjusting screw
20 - Pinless blade holder
