Linear actuator with a stroke range up to 14 mm (0.55 inch) 6DR4004-.N.20
Quantity Designation
1 Sealing
1 Plugs
1 Cable clamp
Equipment you need in addition to the scope of delivery listed below:
● A SIPART PS2 positioner with built-in EMC filter module, order number 6DR5...-....2.
Or:
● An EMC filter module with order number C73451-A430-D23 for retrofitting SIPART PS2 positioners.
In order to prevent interference on the sensor, the mounting elements should be made of non-ferrous antimagnetic metal,
e.g. A4 stainless steel or aluminum.
See also
Mounting (Page 8)
10.3 Scope of delivery of NCS for linear actuators > 14 mm (0.55 inch)
Linear actuator > 14 mm (0.55 inch) 6DR4004-.N.30
Quantity Designation
1 DVD
1 NCS assembly kit, completely
assembled
With this assembly kit, the linear stroke is converted into a rotary movement by means of lever action.
In order to prevent interference on the sensor, the mounting elements should be made of non-ferrous antimagnetic metal,
e.g. A4 stainless steel or aluminum.
Equipment you need in addition to the scope of delivery listed below:
● NAMUR-Linear actuator mounting kit with short lever arm 2 to 35 mm; Order No. 6DR4004-8V.
● With additional extended lever arm for the range from 35 mm to 130 mm; Order No. 6DR4004-8L.
● A SIPART PS2 positioner with built-in EMC filter module, Order No. 6DR5...-....2.
Or:
● An EMC filter module with Order No. C73451-A430-D23 for retrofitting SIPART PS2 positioners.
See also
Mounting (Page 8)
11 Certificate
The certificates can be found on the enclosed CD and on the Internet under:
Certificates (http://www.siemens.com/processinstrumentation/certificates)
SIPART PS2 Non Contacting Sensor (NCS)
A5E00097485-09, 09/2014
All manuals and user guides at all-guides.com
Notes
For cable bushings
For closing the sealing insert
Notes
Containing the complete documentation for all device
variants
Mounting by means of assembly kit for NAMUR linear
actuators (available on separate order; refer to the
accessories section in Catalog FI 01)
19
