Connecting devices to this unit

1 Connect headphones to one of the [HEADPHONES]
terminals.
2 Connect powered speakers, a power amplifier,
components, etc., to the [MASTER OUT 1] or [MASTER
OUT 2] terminals.
! To output the sound from the [BOOTH OUT] terminals, connect
speakers or other devices to the [BOOTH OUT] terminals.
! For details on connecting the input/output terminals, see the
Operating Instructions.
3 Connect this unit to your PC/Mac via a USB cable.
4 Turn on the PC/Mac.
5 Connect the power plug to the AC adapter.
Slide the power plug into the AC adapter's guide rails as shown on the
diagram and press in until a click is heard.
! For detailed cautions on the AC adapter, see "About the AC
adapter" (p. 6 ).
! The shape of the plug differs according to the region in which the
unit is sold.
6 Connect the AC adapter.
7 Press the [ STANDBY/ON] switch on this unit's rear
panel to turn on this unit.
! For Windows users
The message [Installing device driver software] may
appear when this unit is first connected to the PC or when it is
connected to a different USB port on the PC. Wait a while until
the message [Your devices are ready for use] appears.
8 Turn on the devices connected to the output
terminals (powered speakers, power amplifier,
components, etc.).
! When a microphone, DJ player or other external device is
connected to input terminals, the power of that device also turns
on.
