PASO 15 Segment assembly (part 3)
Cover the assembly with another Segment part. Push both parts together to make
sure the center shaft engaged into the top segment too.
Join both parts together using four M3x6 screws.
Turn the assembly around.
Add the fifth M3x6 screw from the other side.
Monta todos los segmentos restantes, utilizando la misma técnica.
PASO 16 Collets: parts preparation
7. Montaje del Casete del buffer
Ensamblaje Original Prusa MMU3
Para los siguientes pasos, por
favor prepara:
Collet (10x)
