Using Your Blender - Haier I-MASTER 5 Serie Manual De Usuario

GB
• Use a higher speed setting.
• Do not attempt to process very thick
ingredients such as bread dough or mash
potatoes.
• Do not operate the appliance at no-load.
Built-in safety lock
• As a safety feature, when the blender
is plugged in, if the lid, jug or knob are
not in the correct position, the motor
will be disabled, and the LEDs will flash
continuously to caution.
• When the lid and jug are properly
installed and the blender is plugged in,
the lightbar LED lights will illuminate in
a clockwise animation for 1 s and the 3
program LED will illuminate indicating the
appliance is ready to use.
Safety Protection
• The blender has a safety protection system
to prevent the motor overheating after a
long time in use.
• When blender is run over 3 minutes, it will
stop processing automatically. If you have
not finished processing after 3 minutes,
switch off the appliance and let it cool
down to room temperature.
• After 3 minutes, if the blender is not in
use, it will automatically go into sleep
mode. Press the program function or
rotate the knob to awaken the blender.
Note: Never use over 3 minutes consecutively.

4. Using your Blender

Glass jug
1. Lower the glass jug onto the multi-serve
jug's blade, rotate the multi-serve jug's
blade clockwise until it locks into place.
[Fig. 1]
2. Lower the glass jug onto the main body,
rotate the glass jug clockwise until it locks
into place. [Fig. 2]
3. Place on a level dry surface such as a
table or work top and plug in. [Fig. 3]
4. Add ingredient to the glass jug. Do not mix
pieces of ingredients larger than 2 x 2 x 2
cm. [Fig. 3]
5. Push down the measuring cup and turn it
clockwise until it locks into the holder of
the lid. [Fig. 4]
6. Fit the lid of multi-serve jug onto the glass
jug to avoid any splashes during blending.
[Fig. 5]
7. The lid hook must be located onto the jug
spout first, the lid handle release must
be pressed under the lid latch when the
lid handle is fully assembled you hear a
"click" sound. [Fig. 5]
8. Once the product is fully assembled, the
preset buttons will illuminate, and the
function will be ready for use. Either press
the preset button to run auto programs or
operate the knob to blend manually. (For
details refer to the function section) [Fig. 6]
9. After blending, unplug it and turn the glass
jug anti-clockwise and pour out to enjoy.
[Fig. 7,8,9,10]
3 buttons function
(Turn the rotary knob to the standby position)
1. Ice crush : Press the button to crush
ice finely with pre-programmed duration
(1min).
2. Smoothie : Press the button to make
smoothie with pre-programmed duration
(1min).
3. Auto clean
with pre-programmed duration (30s).
4. All the programs stop automatically, but
you also can press once to stop.
5. Manual variable speed:
Rotate knob (J) to activate manual variable
speed by rotating between MIN and MAX or
rotate and hold the knob anticlockwise to
to use the pulse function, release knob
to stop.
Personal cup
1. Put the ingredient into the personal cup.
[Fig. 11]
2. Put the personal blender's blade onto the
personal cup and rotate personal blender's
blade clockwise until it locks into place.
[Fig. 12]
3. Rotates the personal cup clockwise until it
locks into the main body, and plug in. [Fig. 13]
4. Select the procedure you want to blend.
(Details refer to previous section) [Fig. 14]
5. After blending, unplug it and remove
the personal cup from the main body by
rotating the cup anti-clockwise.
8
: Press the button to clean
