3.4 Troubleshooting

Diagnostics
The boiler is equipped with an advanced self-diagnosis system. In case of a boiler fault, the display will flash together
with the fault symbol (detail 20 - fig. 1) indicating the fault code. Flashing of the arrows (details 18 and 24 - fig. 1) to-
gether with the error code indicates which boiler shell is in fault status.
There are faults that cause permanent shutdown (marked with the letter "A"): to restore operation just press the RESET
button (detail 8 - fig. 1) for 1 second or RESET on the optional remote timer control if installed; if the boiler fails to start,
it is necessary to first eliminate the fault.
Other faults (marked with the letter "F") cause temporary shutdowns that are automatically reset as soon as the value
returns within the boiler's normal working range.
Table. 4 - List of faults
Fault
Fault
code
A01 The burner fails to light
Flame present signal with
A02
burner off
Overtemperature protection
A03
activation
Fume extraction duct safety
A04
device activation
A05 Fan protection activation
No flame after ignition
A06
stage (6 times in 4 min.)
F07 High fume temperature
F10 Delivery sensor 1 fault
F11 Return sensor fault
F12 DHW sensor fault
86
Possible cause
No gas
Detection/ignition electrode fault
Faulty gas valve
Insufficient gas supply pressure
Trap blocked
Electrode fault
Card fault
Heating sensor damaged
No water circulation in the sys-
tem
Air in the system
Fault F07 generated 3 times in
the last 24 hours
Fault F15 generated for 1 hour
(consecutive)
Ionisation electrode fault
Flame unstable
Gas valve Offset fault
air/fume ducts blocked
Trap blocked
Flue partially obstructed or insuf-
ficient
Fume sensor position
Sensor damaged
Wiring shorted
Wiring disconnected
Sensor damaged
Wiring shorted
Wiring disconnected
Sensor damaged
Wiring shorted
Wiring disconnected
cod. 3540H322 - 09/2008 (Rev. 01)
Reply 51 - 71 - 101
Cure
Check the regular gas flow to the boiler and that the air
has been eliminated from the pipes
Check the wiring of the electrode and that it is correctly
positioned and free of any deposits
Check the gas valve and replace it if necessary
Check the gas supply pressure
Check the trap and clean it if necessary
Check the ionisation electrode wiring
Check the card
Check the correct positioning and operation of the
heating sensor
Check the circulating pump
Vent the system
See fault F07
See fault F15
Check the position of the ionisation electrode and
replace it if necessary
Check the burner
Check the Offset adjustment at minimum power
Remove the obstruction from the flue, fume extraction
and air inlet ducts and terminals
Check the trap and clean it if necessary
Check the efficiency of the flue, fume extraction ducts
and outlet terminal
Check the correct positioning and operation of the
fume sensor
Check the wiring or replace the sensor
Check the wiring or replace the sensor
Check the wiring or replace the sensor
