The third menu is the one defined as EXTENDED 2 and to access the programmable functions follow the instructions given in Tab. 4:
EXTENDED
• Press the SELECT button and scroll the LED menu until
MENU 2
you reach the LEV LED;
• Press SET twice to access the EXTENDED MENU 2.
LIVEL 2 - EXTENDED MENU 2
LED
FUNCTION
DESCRIPTION
L1
SOFT STOP
Setting of gradual slowdown at
the end of the movement
L2
SOFT START
Setting of gradual slowdown at
the beginning of the movement
L3
STOP / PED.
Change logic input 8 CN2 from
BUTTON
STOP (N.C) to P.PED (N.O.)
L4
HOLD-TO-RUN
Hold-to-run input
L5
FOLLOW ME
The motor automatically closes
in 5 sec after passing through
DS1 photocell
L6
LAMP IN PAUSE
Lamp. active during pause
time (if set)
L7
"ALWAYS CLOSE"
Enables the sending of a CLO-
SE command when the power
is turned on again
Table 4
Important note: The control unit allows to be programmed if all the safety devices and buttons (N.C. inputs on terminals) grant a contact closed.
7 DETAILED
DESCRIPTION
FUNCTIONS
7.1 ELECTRICAL CONNECTIONS
CN1:
L:
230 V~ Line input (Phase)
N:
230 V~ Line input (neutral)
MOT1 OPEN:
Motor 1 opening output.
MOT1 COM:
Motor 1 common output.
MOT1 CLOSE:
Motor 1 closure output
MOT2 OPEN:
Motor 2 opening output.
MOT2 COM:
Motor 2 common output.
MOT2 CLOSE:
Motor 2 closure output
CN2:
ELS:
Free contact output for Electric lock
ELS+:
Free contact output for Electric lock
FOTO+:
Photocell control and power supply (24V 5W)
GND:
Photocell control and power supply (GND)
DS2:
Safety device input 2 (NC) active in opening
GND:
Common GND input
DS1:
Safety device input 1 (NC) active in closure
STOP:
STOP button input (N.C.)
GND:
Common GND input.
PP:
Step-by-Step open-close/close command button
input (NO)
ANT-:
Antenna chassis input
ANT+:
Antenna hot pin input
TRANSFORMER CONNECTIONS
CN3 1st:
1 : 230 V~ Transformer Primary Winding Input.
2 : 230 V~ Transformer Primary Winding Input.
CN4 2nd:
1. Transformer SEC 1 Output 12.5V 0.17A no-load voltages.
2. Transformer SEC 1 Output 12.5V 0.17A no-load voltages.
3. Transformer SEC 2 Output 24.5V 0.4A no-load voltages.
4. Transformer SEC 2 Output 24.5V 0.4A no-load voltages.
7.2 FUNCTIONAL CHARACTERISTICS
7.2.1 AUTOMATIC OPERATION (OPEN/CLOSE):
Using both the remote control (LED L2 CODE lit) and the keypad in low
The LED of the LEV function FLASHES with this frequency
LED ON
Enabled function
Enabled function
Pedestrian Button (N.O.)
Enabled function
Enabled function
Enabled function
Enabled function
OF
ALL
voltage for the actuation of the shutter, you will get the following operation:
The first pulse commands opening until the lapse of the motor time upon
reaching the opening limit switch, the second pulse commands closure of
the shutter; if a pulse is sent before the motor time has lapsed or one of
the two limit switches has been reached, the control unit will reverse the
movement both in opening and in closure.
7.2.2 STEP-BY-STEP OPERATION:
With the function enabled (LED L2 on), using either the remote control or
the low voltage buttons to activate the shutter, the following operating logic
is obtained: the first pulse commands opening until the motor time lapses
or until the opening limit switch is reached, the second pulse commands
closure of the shutter; if a pulse is sent before the motor time lapses or
before the opening limit switch is reached, the control unit will stop move-
ment (if a pause time was previously programmed, the control unit will exe-
cute automatic re-closure when the time lapses). An additional command
determines the resumption of movement in the opposite direction; if a
pulse is sent before the motor time lapses or before the closing limit switch
is reached, the control unit will always stop movement. A further command
determines the resumption of motion in the opposite direction.
7.2.3 STEP-BY-STEP WITH CLOSURE
With the enabled function, when either the remote or the low voltage
control pushbuttons are used to control the gate, operation is as follows:
the first command opens the gate until motor time or until the gate reaches
its opening limit position; the second command closes the gate; if another
command is transmitted before motor time has elapsed or before one of
the limit stops has been reached, the control unit always stops the move-
ment both during the opening and closing phases (even if the pause time
has been previously programmed). Another command causes the gate to
start moving again in the opposite direction. (see section 7.2.3).
7.2.4 AUTOMATIC CLOSING
The control unit can be set up to close the gate automatically without
sending any additional commands.
The selection of this type of operation is described in Pause time program-
ming mode PAUSE TIME (see section 7.1.6).
7.2.5 PEDESTRIAN OPENING
The control unit allows, using either the remote control or the Pedestrian
button, the activation of only Motor 1 for a programmable time.
EMERGENCY STOP INPUT:
The control unit allows the connection of the emergency stop button (NC).
Intervention of the control unit during any stage of operation causes move-
ment to immediately stop. An additional movement command will be valid
LED OFF
Disabled function
Disabled function
STOP (N.C.)
Disabled function
Disabled function
Disabled function
Disabled function
