FIGURE 23
FIGURE 25
FRONT
CYLINDER #1
CYLINDER #3
Install The Starter Motor
1. Install the starter motor to the engine.
2. Torque the starter motor bolts to 30 ft-lbs.
3. Connect the positive battery cable and starter wiring to
the starter motor.
502/502 Big Block Chevrolet Engine Pkg.
TITLE
BOLT
SUPPORT
FRT
DISTRIBUTOR
ASSEMBLY
RETAINER
CYLINDER #5
RETAINER
ROCKER COVER ASSEMBLY
SUPPORT
FRT
RETAINER
SUPPORT
CYLINDER #7
RETAINER
SUPPORT
CYLINDER #8
CYLINDER #6
12368083
REV 16JA15
PART NO.
FIGURE 24
BOLT
ROCKER COVER
ASSEMBLY
FIGURE 26
FRONT
RETAINER
TUBE ASSEMBLY
RETAINER
CYLINDER #4 CYLINDER #2
13
SHEET
63
OF
