BONFIGLIOLI Vectron ACU-P Serie Manual Del Usuario página 33

GB
D
The diameter of he fixing holes is 9mm.
Screwing the heat sink back panel of the frequency inverter to the assembly panel.
Dimensions without optional
ACU-P
401
Cotas
05/ 2014
ACU-P (75,0 to 132,0 kW)
x
300 mm
b
x
a
x
x
300 mm
a1
components:Cotas de mntaje en
Dimensions [mm]
kW a
75,0...132,0 510
31
c
c1
c2
c3
b1
b2
b3
Installation dimensions [mm]
b c a1
412 351 480
c1
338
b1 b2 b3
392 382 242
c2 c3
305 110
Quick Start Guide ACU-P
