INSTALLING THE BRUSHES (DISC SYSTEM)
CAUTION!
Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
1 Make sure the Scrub Deck (8) is in the RAISED position. Make sure the Key Switch (A) is off (O).
2 If using pads, install the pads on the pad holders.
3 See Figure 2. To mount the Brushes (AA) (or pad holders) align the Lugs (BB) on the brush with the holes on the mounting plate and turn to
lock in place (turn the outside edge of brush towards the rear of machine as shown (CC)). NOTE: During operation the brushes should rotate
in direction (DD).
FIGURE 2
BB
CC
DD
3/2019
INSTRUCTIONS FOR USE
CC
DD
56091217 - SC901 ST
8
AA
ENGLISH - A
A - 11
