Important!

After having effected the conversion to another type of gas, it is necessary to update the data plate, indicating the type
of gas for which the appliance has been converted.
• The appliance contains the instructions necessary for use.
• Check the appliances for gas leaks.
• Examine the flame of the pilot burner; it must lap the thermocouple and be blue, otherwise examine the nozzle of
the pilot burner.
• Check the lighting and flame of the main burner.
• We urge the user to follow the instructions when using the appliance.
With prolonged use of the appliance, it is indispensable to carry out regular maintenance for the safe functioning of the
appliance; we therefore recommend drawing up a contract for after sales service.
Maintenance must be done only by specialized personnel, observing the norms in force and our indications.
It is possible to substitute parts such as the valve, the piezoelectric lighter or gas pipes very simply.
To substitute the parts, proceed as follows:
• Valve: after removing the front panel, unscrew the screwed fittings (04-05) of the gas connections and take out the
bulb of the thermostat, then substitute the faulty parts, installing the new ones.
• To substitute the thermocouple, unscrew the fitting (06) of the valve and substitute the element.
• The spark plug (07) must be unscrewed and substituted.
Attention! In the event that smoke is given off, when the appliance is started up, it is necessary to let the installation
function without being used, for approximately an hour or until the smell disappears.

Lighting the pilot burner

Push and turn the thermostat knob (01) into position
Keeping the knob pushed down, press the piezo button (03) repeatedly. The flame lights automatically and can be seen
trough the inspection hole in the front panel. After lighting, hold the knob down for another 5-10 seconds, to allow the
thermocouple to warm up, then release it. The flame may go out, in which case it is necessary to repeat the procedure.

Lighting the main burner and regulating the temperature

After releasing the knob, the gas goes into the safety valve. Turning the graduated knob from 60 to 300° C, the gas goes
to the main burner whcih then lights.

Putting out the main burner

Turn the knob into position

Turning off the appliance

Push and turn the knob into position "0". This command blocks the gas supply to both the main burner and the pilot
burner.
The drip pan must be checked regularly and emptied before getting full. In any event, the pan must be cleaned after
switching off the appliance.

INSTRUCTIONS FOR DISCHARGING GAS EMISSIONS

Type "A" Appliances (see data plate)

Type "A" appliances must discharge the products of combustion into extractor hoods or similar devices connected to
and efficent chimney, or directly outside. (Natural Discharge Fig.1)
If there is not a hood, as an alternative, an air extractor connected directly to the outside is acceptable, (Forced
Discharge Fig.2) but its capacity must not be inferior to what is established in item 4.3 of the UNI-CIG norm 8723.
GB

CHECKING FUNCTIONING

MAINTENANCE

SPARE PARTS FIG.B

INSTRUCTIONS FOR USE

LIGHTING THE MAIN BURNER

;only the flame of the pilot burner remains lit.

DRIP PAN
