Unit Installation – BH/B Units
G Check the dimensions of the unit illustrated in the following figure:
Nx Ø200
Air Outlet
Unit Dimension A
Hanging Bolt Pitch B
J = M x K
Model (RAV-)
264BH 1000 1050 1080 15.9
364BH/B, 464BH/B 1350
164BH/B 700
264B 1000
Installing Ø 10 Hanging Bolts (4 pieces)
G
Install the hanging bolts at the intervals shown in the
following figure.
G
Use Ø 10 hanging bolts (to be locally procured).
Ceiling preparation: The actual procedure differs according
to the structure. Consult your builder or whoever was
responsible for the interior of the house/building.
Removal of part of the ceiling plate:
(1) In order to ensure that the ceiling is kept perfectly
horizontal and to prevent the ceiling from vibrating, the
ceiling framework must be reinforced.
(2) Cut and remove part of the ceiling framework.
(3) Reinforce the ends of the ceiling framework where it was
cut and add framework to secure the ends.
G
Some piping and wiring connections must be made in the
ceiling after the unit has been suspended. After selecting where
the unit will be installed, decide on the direction of the piping
connection. If the ceiling is already installed, prepare the
refrigerant pipes, drain pipe, indoor to outdoor unit connection
wiring and the remote control cord at the piping and wiring
connection positions before suspending the indoor unit.
How to Install the Hanging Bolts
Installation on a newly installed concrete slab:
Use insert brackets or foundation bolts for the installation.
Knife shaped Sliding bracket
bracket
Tel: 01823 665660
All manuals and user guides at all-guides.com
I U L
NDOOR NIT
Hanging Bolt
4-M10
Provided at site
Refrigerant Pipe
Connection
(H)
(Gas ø F)
Refrigerant pipe
connection
(liquid ø G)
Drain pipe connection
(inner diameter 32)
(diameter 32 minimal for PVC pipes)
A B E Ø F Ø G
9.5
1400 1430 19.0 9.5
750 780 12.7 6.4
1050 1080 15.9 9.5
Installation on an existing con-
crete slab:
Use hole-in anchors, hole-in plugs
or hole-in bolts for the installation.
Installation on a steel frame:
Use the angular
bracket in
the structure
or install
one for support.
Installation on a wooden structure:
Place a length of wood of the appropriate size across two
beams and install the hanging bolts onto this length of wood.
Reinforcing Hanging Unit
bar
(1) Raise the unit by using a lift-
Foundation bolt
(Foundation bolt for
hanging the piping)
(2) Install the unit horizontally
~ 11 ~ ~ 11 ~
www.heronhill.co.uk
OCATION
Unit Dimension:800
Hanging Bolt Pitch:565
6 x Ø4 holes (Ø160)
H J K M N
252 580 290 2 3
252 930 310 3 4
252 280 280 1 2
252 580 290 2 3
Hanger
bolt
Hanging bolt
Cross
length of
wood
Hanging
bolt
ing device, then secure the
hangers to the hanging
bolts. Be sure to fix the nuts
onto both the upper and
Washer
under side of the hanger
Hanging
and the washer (under side
Bolt
only);
by using a level. Failure to
do this will cause water
leakages.
Fax: 01823 665807
Fresh air inlet Ø125
cut-out (other side)
Filter kit
GB
Angular bracket
for support
Beam
Ceiling
Nut
Hanger
