Trabajo de cableado eléctrico
C/O
Combinación estándar
Modelo
AM080AXVANC/EA
AM100AXVANC/EA
AM120AXVANC/EA
AM140AXVANC/EA
AM160AXVANC/EA
AM180AXVANC/EA
AM200AXVANC/EA
AM220AXVANC/EA
AM240AXVANC/EA
AM260AXVANC/EA
AM280AXVANC/EA
AM300AXVANC/EA
AM320AXVANC/EA
AM340AXVANC/EA
AM360AXVANC/EA
AM380AXVANC/EA
AM400AXVANC/EA
AM420AXVANC/EA
AM440AXVANC/EA
AM460AXVANC/EA
AM480AXVANC/EA
AM500AXVANC/EA
AM520AXVANC/EA
AM540AXVANC/EA
AM560AXVANC/EA
AM580AXVANC/EA
AM600AXVANC/EA
AM620AXVANC/EA
AM640AXVANC/EA
AM660AXVANC/EA
AM680AXVANC/EA
AM700AXVANC/EA
AM720AXVANC/EA
AM740AXVANC/EA
AM760AXVANC/EA
AM780AXVANC/EA
AM800AXVANC/EA
AM820AXVANC/EA
AM840AXVANC/EA
AM860AXVANC/EA
AM880AXVANC/EA
AM900AXVANC/EA
AM920AXVANC/EA
AM940AXVANC/EA
AM960AXVANC/EA
AM980AXVANC/EA
46
Español
DB68-11597A-02_IM_DVM S2 Outdoor_EA_ES_.indd 46 DB68-11597A-02_IM_DVM S2 Outdoor_EA_ES_.indd 46
MCA MFA
19,0 25
23,0 32
26,0 32
29,0 32
34,0 40
39,2 50
43,0 50
44,6 50
55,0 63
60,0 75
61,0 75
68,6 75
68,6 75
73,0 80
80,0 100
84,0 100
87,0 100
90,0 100
95,0 125
100,2 125
104,0 125
105,6 125
116,0 150
121,0 150
122,0 150
128,0 150
133,0 150
134,0 150
141,6 175
141,6 175
146,0 175
151,0 175
156,0 175
161,2 200
165,0 200
166,6 200
177,0 200
182,0 200
183,0 225
185,2 225
189,0 225
190,6 225
201,0 225
206,0 250
207,0 250
214,6 250
Combinación de alta eficiencia
Modelo MCA
AM080AXVANC/EA 19,0
AM100AXVANC/EA 23,0
AM120AXVANC/EA 26,0
AM140AXVANC/EA 29,0
AM160AXVANC/EA 34,0
AM180AXVANC/EA 39,2
AM200AXVANC/EA 43,0
AM220AXVANC/EA 44,6
AM240AXVANC/EA 55,0
AM260AXVANC1EA 57,0
AM280AXVANC1EA 62,0
AM300AXVANC1EA 66,0
AM320AXVANC1EA 69,0
AM340AXVANC1EA 72,0
AM360AXVANC1EA 77,0
AM380AXVANC1EA 82,2
AM400AXVANC1EA 86,0
AM420AXVANC1EA 87,6
AM440AXVANC1EA 98,0
AM460AXVANC1EA 103,0
AM480AXVANC1EA 105,0
AM500AXVANC1EA 109,0
AM520AXVANC1EA 112,0
AM540AXVANC1EA 115,0
AM560AXVANC1EA 120,0
AM580AXVANC1EA 125,2
AM600AXVANC1EA 129,0
AM620AXVANC1EA 130,6
AM640AXVANC1EA 141,0
AM660AXVANC1EA 146,0
AM680AXVANC1EA 148,0
AM700AXVANC1EA 152,0
AM720AXVANC1EA 155,0
AM740AXVANC1EA 158,0
AM760AXVANC1EA 163,0
AM780AXVANC1EA 168,2
AM800AXVANC1EA 172,0
AM820AXVANC1EA 173,6
AM840AXVANC1EA 184,0
AM860AXVANC1EA 189,0
AM880AXVANC1EA 190,0
AM900AXVANC1EA 197,6
AM920AXVANC1EA 197,6
AM940AXVANC1EA 213,0
AM960AXVANC1EA 218,0
AM980AXVANC1EA 223,0
MFA
25
32
32
32
40
50
50
50
63
63
75
75
75
80
100
100
100
100
125
125
125
125
125
150
150
150
150
150
175
175
175
175
175
175
200
200
200
200
225
225
225
225
225
250
250
250
