24 | English
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1) Assembly holes
(2) Clamping screw for saw table extension
(3) Saw table extension
(4) Recessed handles
(5) Scale for mitre angles
(6) Adjustable fence
(7) Screw clamp
(8) Stop for standard 45° bevel angle
(9) Stop screw for 45° bevel angle
(10) Clamping handle for all bevel angles
(11) Locking screw for slide device
(12) Slide device
(13) Chip ejector
(14) Chip deflector
(15) On/off switch
(16) Handle
(17) Locking switch for releasing the tool arm
(18) Protective guard
(19) Retracting blade guard
(20) Guide roller
(21) Fence
Technical Data
Sliding mitre saw
Article number
Rated power input
No-load speed
Starting current limitation
Weight according to EPTA-Procedure 01:2014
Protection class
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-
specific models.
Permissible workpiece dimensions (see "Permissible workpiece dimensions", page 28)
Dimensions of suitable saw blades
Saw blade diameter
Base blade thickness
Max. cutting width
Hole diameter
Noise Information
Noise emission values determined according to
EN 62841-3-9.
1 609 92A 7NC | (26.04.2022)
(22) Saw table
(23) Insert plate
(24) Angle indicator for mitre angles
(25) Locking knob for all mitre angles
(26) Mitre pre-setting lever
(27) Tilt protector
(28) Detents for standard mitre angles
(29) Spindle lock
(30) Transport safety lock
(31) Scale for bevel angles
(32) Angle indicator for bevel angles
(33) Stop screw for 0° bevel angle
(34) Stop for standard 0° bevel angle
(35) Hex key (5 mm)/cross-headed screwdriver
(36) Hex socket screw for mounting the saw blade
(37) Clamping flange
(38) Inner clamping flange
(39) Saw blade
(40) Locking screw for the adjustable fence
(41) Holes for screw clamp
(42) Threaded rod
(43) Screws for insert plate
(44) Screw for bevel angle indicator
(45) Screw for mitre angle indicator
W
-1
min
kg
Typically, the A-weighted noise level of the power tool is:
Sound pressure level 93 dB(A); sound power level
mm 216
106 dB(A). Uncertainty K = 3 dB.
mm 1.3−1.8
Wear hearing protection!
mm 3.3
The noise emission value given in these instructions has
mm 30 been measured in accordance with a standardised measur-
ing procedure and may be used to compare power tools. It
may also be used for a preliminary estimation of noise emis-
sions.
GCM 80 SJ
GCM 800 SJ GCM 800 SJ
GCM 8000 SJ GCM 8000 SJ
3 601 M19 0.. 3 601 M19 06.
1400
5500
●
14.1
/ II
Bosch Power Tools
GCM 80 SJ
1250
5500
●
14.1
/ II
