Connecting the Auto-Fill Function

Use the following procedure to connect the unit to the on-site
water supply for the Auto-Fill function. A qualified installer
should perform the water connections.
NOTE: HEATMAX Heated Wells have a built-in backflow
prevention assembly.
1. Connect the on-site water supply line to the G 1/2" BSPP
water inlet fitting on the unit.
• RCTHW2-x = G fitting on the back of the unit.
• RCTHW2-xB = G fitting on the bottom of the electrical box.
2. Turn on the water supply and check for leaks.
NOTE: If the incoming water sprays out of the well while filling,
turn down the water pressure using the shut off valve
on the on-site water supply line.
RCTHW2CEM-0124

Electrical Connections

RCTHW2-6 and RCTHW2-6B models are equipped with a
power cord only. These units must have the appropriate plug
installed or be hardwired to the electrical supply.
NOTE: The specification label is located on the back of
countertop units and the bottom of built-in units. See
label for serial number and verification of unit electrical
information.
ELECTRIC SHOCK HAZARD: Units supplied without a
plug require field installation of proper plug or a hardwired
connection to on-site electrical system. Connection must
be properly grounded and of correct voltage, size, and
configuration for electrical specifications of unit. Contact
a qualified electrician to determine and install proper
electrical connection.
Make sure electrical supply matches voltage and frequency
rating on specification label. Incorrect electrical supply
may damage unit.
Hardwired Connection
Make the appropriate connections from the power cord to the
on-site power supply.
Plug Connection
Connect the proper plug to the power cord. Make sure the plug
is rated for the specific load and the plug matches a suitable
receptacle.
NOTE: The plug and receptacle must be grounded in
accordance with current standards.
9
INSTALLATION
WARNING
NOTICE
