Always ground this machine. It is recommended to ground the machine for your own safety if it
is used with a power supply which is fitted with a current-operated earth leakage circuit breaker
having the rated sensitivity current of 15 mA max. and the operating time of 0.1 seconds max.
When the receptacle used does not have a ground slot, the earth clip and earth (ground) wire,
confirm that they are without fault.
When you have a tester or an insulation resistance meter, check for continuity between the earth
clip and the machine's metal frame. Grounding work (for example, burying the earth pole (earth
plate, earth bar) in the ground and connecting the earth (ground) wire must be done by a quali-
fied electrician.
*2 Extension Cord: When an extension cord is required for use with a distant power supply, is
should be thick enough to carry a current and as possible to ensure that the product is used
with the maximum efficiency without a failure. The extension cord used must be a three-cord
cab tyre cable having one earth (grounding) core.
4

Function of the Unit

4.1 Overview
1
Front cover
2
PORTACUT plate
3
Company plate
5 Saw Blade Replacement seal
6 Oblique cutting adjustment seal
7 Frame
8 Tension handle
9 Following pulley
10
Driving pulley
11
Bearing
12 Saw blade
13 Blade guide head F
14 Blade guide head R
15 Dog
16 Handle
18
Cutting load adjustment spring
19
Cable holder
20 Chain vice
4.2

Operation

The following gives a general description of work including the pipe cutting:
 Prepare for operation
 Install the work on this machine
 Cutting the pipe
 Remove the cut pipe
The following describes the contents of the above procedures.
4.3 Preparing for Operation
The saw blade selected should have T.P.I. which matches the work piece. For saw
blade selection, refer to the cutting load chart on the machine or in the instruction
manual!
16
21
Off-Switch
22
Chain
23
Chain handle
24 Clamp knob
25 Feed screw guide
26 Clamper
27 Stop bolt
28 Chain holder
29
Overload protection switch
30
On-Switch
PORTACUT 185 BSP:
31 Threaded rod
32 Rear clamping plate
33 Front clamping plate
35 Motor
36
Bearing housing
37
Bearing box
39 Clamp handle
