4. FRONT PANEL DESCRIPTION

A. Surface velocity/length adapter measurement
B. RPM measurement adapter (TW-01)
C. Conel Type Rubber (TC-02)
D. Funnel Type Rubber (TF-02)
E. Axis
F. Function selector
G. 6V DC Adapter Input (Adapter not provided).
H. Action key, trigger to perform measurements
I. "MEM" Key
J. LCD Display
K. Battery cover (rear side)
C
D
B
F
m
m/min
rpm
G
MEM
J
8. 8 . 8 . 8 . 8
_
+
DIGITAL TACHOMETER
Figure 1
17
A
E
H
I
K
RPM
