9.6 Fixing the vacuum cleaner to the wall
The vacuum cleaner must be securely and permanently fi xed to a solid wall using the bracket provided
and the suitable wall anchors or plugs taking into account that the total weight to be supported can be
seven/eight times that of the system itself.
The system should be positioned high enough off the ground to allow the dust collection bin to be
emptied and the fi lter to be replaced in a simple way.
Position the system so as to keep a minimum distance of 60 cm around the appliance for extraordinary
maintenance.
To do this follow the instructions detailed below:
Trace the drilling position using the template provided
(drilling template); if this has already been done, proceed to
Height from the ground is detailed in the table below:
Model
Item
X Size (min.)
21/01/16 Rev:3.0.0
the next step.
TECNO R-evolution
Tecno
R-evolution 150 R-evolution 250
3110.2T
mm 500
Drill the holes
2
1
Tecno Tecno
R-evolution 350
3112.2T 3113.3T
500 500
2
Tecno
R-evolution 450
3115.3T
500
