MODEL F-A (PNEUMATIC) HANDLE AND DRIVE
ITEM QUAN.
1 1
2 2
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 2
11 1
12 1
13 1
14 1
15 1
16 2
17 1
18 1
19 1
20 1
21 10
22 1.5 ft.
23 1
24 1
25 1
26 1
27 1
28 1
29 1
30 1
31 1
32 1
33 1
34 4" (102mm)
35 1
36 1
37 1
38 1
39 1
40
41 1
42 1
43 1
44 4.5" (114mm)
45 2
46 1
47 2
48 2
68
®
FISCHBEIN F SERIES PORTABLE SEWING MACHINES
OPERATOR'S MANUAL
PLATE "G"
PART NO.
SF832516
PS6.6X40
11018
11012
11017
WIT8
NH832
11340
11339
SB103212
11011
SC44034
11327
11863
PT8OZWHITE
SC142034
11326
11804
11815
11805
SF103238
P4969
P4976
18107
11346
11336
11335
11338
PS18138
11337
11906
B83212
11450
85128
11472
B832114
11475
11478
11479
WN8
11490
11485
11453
85128
11908
11802
WN8
SB103214
REV. H 9/2011
DESCRIPTION
Screw, Soc. Flat 8-32 X 5/16"
Spring Pin - 1/4" X 1 1/2" Long
Belt Guard, Top
Hanger
Clip, Hanger
Washer, Internal Tooth #*
Nut, Hex 8-32
Belt, Timing Drive
Pulley, Main Shaft Timing
Screw, Soc. Btn. 10-32 X 1/2"
Handle Cover
Screw, Soc. Cap 4-40 X 3/4"
Valve and Maniffold Assy.
Coupling
Thread, Poly 8 oz. Cone (White)
Screw, Soc. Cap 1/4-20 X 3/4"
Handle
Thread Guide and Cone Holder
Thread Stand
Nut, Wing-Washer Base-1/4-20
Screw, Soc. Flat 10-32 X 3/8"
Motor Air Supply Tubing
Nylon Clip
Male Elbow 1/4" Pipe X 3/8" Tubing
90 deg. Elbow 1/4" NPT Male X 1/4" NPT Fem.
Air Motor Mounting Strap
Air Motor
Motor Timing Pulley
Spring Pin 1/8" Dia. X 1 3/8"
Air Motor Mount
Motor Mount Hinge Assy.
Screw, Inding Hd. 8-32 X 1/2"
Oil Pump Assy.
Oil Pump Tubing
Garter Spring
Screw, Binding Hd. 8-32 X 1 1/4"
Outside Manifold
"O" Ring
"O" Ring
Washer, Nylon-#8
Barbed Fitting
Inside Manifold Weldment
Cap, Oil Reserve
Plastic Tubing
Screws, Sems-Pan HD 6-32 X 7/16
Guard, Pulley Drive – Modified for Air Motor
Washer, Nylon #8
Screw, Soc Bttn #10-32 X 1/4 BO
