3.3.12 Nodo lógico IEC61850
Data Object Common Data
Name
LNName
Data Objects
Status information
ProTx SPS
ProRx SPS
Str ACD
Op ACT
LosOfGrd SPS
Echo ACT
WeiOp ACT
RvABlk ACT
Settings
SchTyp ENG
CrdTmms ING
DurTmms ING
SecTmms ING
WeiMod ENG
RvAMod ENG
RvRsTmms ING
Extended Data
CarStop EXT_SPC
OvStr EXT_ACD
RvStr EXT_ACD
CarWavFail EXT_SPS
CarStopOut EXT_SPS
CarOpnCB EXT_SPG
PhGndVal EXT_ASG
M0ZLFA1807E
3.3-19
ZLF: Protección de Distancia
© ZIV APLICACIONES Y TECNOLOGÍA, S.L.U. 2018
3.3 Esquemas de Protección de Sobreintensidad
CLASS IRLPSCH
Class
The name shall be composed of the class name, the LN-Prefix
and LN-Instance-ID according to IEC 61850-7-2, Clause 22
Teleprotection signal transmitted
Teleprotection signal received
Carrier send
Operate
Loss of guard
Echo signal from weak end infeed function
Operate signal from weak end infeed function
Block signal from current reversal function
Scheme Type
Co-ordination timer for blocking scheme
Minimum duration of carrier send signal
Pickup security timer on loss of carrier guard signal
Mode of weak end infeed function
Enable of current reversal function
Delay time for coordination
Stop of the channel input in directional comparison block
scheme
Start of the overreach overcurrent unit input
Start of the inverse overcurrent unit input
Fail in the communication equipment
Stop of the channel in directional comparison block scheme
Sent due to breaker open status
Undervoltage level for weak infeed function
Explanation
