en
Please keep this instruction manual in a safe place.
When passing the vacuum cleaner on to another
person, please also hand over this instruction manual.
Fold out the picture pages.

Your vacuum cleaner

1 Adjustable floor tool with locking collar*
2 Hard-floor brush with locking collar*
3 TURBO-UNIVERSAL® brush for floors*
4 Telescopic tube with adjusting sleeve
(and locking collar)*
5 Telescopic tube with sliding switch
(and locking collar)*
6 Handle
7 Flexible hose*
8 Upholstery nozzle*
9 Crevice nozzle*
10 Dust bag change indicator*
11 On/off button
12 Parking aid
13 Power cord
14 Exhaust grille
15 Carrying handle
16 Dust bag compartment lid
17 Accessories compartment
18 Dust bag
19 Motor protection filter, washable
20 Exhaust filter*
21 Storage aid (on underside of appliance)
Replacement parts and special
accessories
A Dust bag
To get the most out of your appliance, we recom-
mend using PowerProtect genuine replacement bags
(VZ41FGALL).
Contents:
• 4 dust bags with fasteners
• 1 micro-hygiene filter
! PLEASE NOTE
Your appliance is a highly efficient vacuum cleaner
that can only achieve its best cleaning results using
genuine dust bags.
Only if high-quality dust bags are used, such as
genuine Siemens dust bags, can the figures speci-
fied on the EU energy label pertaining to energy effi-
ciency class, suction and dust retention capacity be
achieved.
Additionally, using inferior quality dust bags (e.g.
paper bags) can have a significant impact on the
service life and performance of your appliance.
Warranty claims can only be made if genuine
Siemens dust bags are used.
For more information and to order genuine Siemens
dust bags, go to
www.siemens-home.com/dust-bag
B Hepa filter VZ154HF
Additional, washable filter for cleaner exhaust air.
Recommended for allergy sufferers.
C TURBO-UNIVERSAL® brush for upholstery VZ46001
All-in-one brushing and vacuuming of upholstered
furniture, mattresses, car seats, etc. Especially sui-
table for picking up pet hair. The brush roller is dri-
ven by the suction air flow of the vacuum cleaner.
No separate electrical connection is needed.
D TURBO-UNIVERSAL® brush for floors VZ102TBB
All-in-one brushing and vacuuming of short-pile rugs
and carpets, and for all floor coverings. Especially
suitable for picking up pet hair. The brush roller is
driven by the air flow through the vacuum cleaner.
No separate electrical connection is needed.
E Hard-floor tool VZ123HD
For vacuuming hard floors
(parquet, tiles, terracotta, etc.)
Before using for the first time
1*
Figure
● Push the handle onto the flexible hose and lock it in
place.
2
Figure
● Open the accessories compartment.
● Insert the crevice nozzle and upholstery nozzle in the
accessories compartment in the appliance lid.
● Close the accessories compartment.

Initial use

3
Figure
a)Push the flexible hose adapter into the air intake
opening in the vacuum cleaner lid until it locks into
place.
b)To remove the flexible hose, press the two catches
together and pull out the hose.
4*
Figure
● Push the handle into the telescopic tube until it
locks in place.
● To release the connection, press the locking collar
and pull out the telescopic tube.
* depending on model
