A-4

ELECTRICAL CONNECTIONS

544A
(Male)
543A
(Female)
J7 (10-pin)
J8 (6-pin)
P7 (10-pin)
8. Adapter harness. All 6 connections shown are
used, and each one is unique. (Proceed as follows)
9.A. Remove P3 (10-pin) from board J3 (10-pin).
9.B. Connect P3 (10-pin) to harness J7 (10-pin).
INSTALLATION
Toggle Switch
10. Connect harness P7 (10-pin) to board J3 (10-
P8 (6-pin) pin).
IF MACHINE DOES NOT HAVE OPTIONAL SPOT TIMER.
(11.A. thru 11.D.)
P3
J3
11.A. Remove P5 (6-pin) from board J5 (6-pin).
P3
J7
11.B. Connect P5 (6-pin) to harness J8 (6-pin).
11.C. Connect harness P8 (6-pin) to board J5 (6-
MAGNUM 100SG SPOOL GUN
P7
pin).
A-4
J3
P5
J5
J8
P5
P8
J5
