4 Consumables
Only synthetic resin-bonded, fiber-reinforced discs with maximum Ø 125 mm which are approved for use at
a rotational speed of at least 11,000/min and a peripheral speed of 80 m/s may be used.
The maximum permissible grinding disc thickness is 6.4 mm and the maximum permissible cutting disc
thickness is 3 mm.
ATTENTION! When cutting or slitting with abrasive cutting discs always use the standard guard with
the additional front cover, or a fully enclosing dust hood.
Discs
Abrasive cutting disc
Diamond cutting disc
Abrasive grinding disc
Diamond grinding disc
Diamond core bit
Suitability of discs for the equipment used
Item Equipment
A Guard
B Front cover (in combina-
tion with A)
C DG-EX 125/5" dust hood
for grinding
D DC-EX 125/5"C dust
hood for cutting (only in
conjunction with A)
E Side handle
F DCBG 125 hoop handle
(optional for E)
G Clamping nut
H Clamping flange
I Kwik lock (optional for G)
5

Technical data

Rated voltage
Rated speed
Maximum disc diameter
Weight in accordance with EPTA procedure 01
Drive spindle thread (arbor size)
Spindle length
5.1 Noise information and vibration values in accordance with EN 60745
The sound pressure and vibration values given in these instructions were measured in accordance with a
standardized test and can be used to compare one power tool with another. They can also be used for a
preliminary assessment of exposure. The data given represents the main applications of the power tool.
However, if the power tool is used for different applications, with different accessory tools, or is poorly
maintained, the data can vary. This can significantly increase exposure over the total working period. An
accurate estimation of exposure should also take into account the times when the tool is switched off, or
when it is running but not actually being used for a job. This can significantly reduce exposure over the
total working period. Identify additional safety measures to protect the operator from the effects of noise
2111866
*2111866*
Printed: 18.06.2018 | Doc-Nr: PUB / 5223753 / 000 / 03
Application
Cutting, slitting
Cutting, slitting
Rough grinding
Rough grinding
Drilling in tiles
AC­D AG-D AF-D
X X X
X — —
— — —
— — —
X X X
X X X
X X X
X X X
X X X
Designation Material
AC­D Metal
DC-TP, DC-D (SPX, Mineral
SP, P)
AG­D, AF­D, AN­D Metal
DG-CW (SPX, SP, Mineral
P)
DD-M14 Mineral
AN-D DG­CW DC­D
X X
— —
— X
— —
X X
X X
X X
X X
X —
AG 125­A22
21.6 V
9,500 /min
125 mm
2.7 kg
M14
22 mm
DD-M14
X X
X —
— —
X —
X X
X X
X —
X —
X —
English 23
