Operating Instructions - Flex LD 15-10 125 R Manual Del Usuario

LD 15-10 125 R / LD 15-10 125

Operating instructions

Before switching on the power tool
 Unpack power tool and accessories
and check that no parts are missing
or damaged.
Inserting and changing the sanding
tools
t^okfkd>
_ÉÑçêÉ=éÉêÑçêãáåÖ=~åó=ïçêâ=çå=íÜÉ=ÉäÉÅíêáÅ=
éçïÉê=íççäI=éìää=çìí=íÜÉ=ã~áåë=éäìÖK
 Press and hold down the spindle lock (1.).
 Using the stop key, loosen the clamping nut
on the spindle in an anti-clockwise direction
and remove (2.).
 Insert diamond sanding pad (A) correctly.
 Screw the clamping nut (B), with flange face
up, onto the spindle.
 Press and hold down the spindle lock.
 Tighten the clamping nut with the stop key.
 LD 15-10 125 R:
Check position of the guard:
The brush ring should protrude over the
sanding pad by approx. 0–1 mm. If required,
correct (see "Adjusting the guard (LD 15-10
125 R)").
 Insert the mains plug into the socket.
 Switch on the electric power tool (without
locking the button) and leave it running for
approx. 30 seconds. Check for imbalances
and vibrations.
 Switch off the electric power tool.
19
