Assembly And Adjustments - DeWalt DW733 Traducido De Las Instrucciones Originales

EngLIsh
Handholds
7
Depth adjustment scale
8
Material removal scale
9
10 Front table extension
Fig. a2
Cord wrap
11
Tool tray
12
Dust extraction adaptor
13
14 Depth stop
Base
15
Intended Use
Your D WALT DW733 thickness planer has been designed for professional cutting of wood. It
e
performs planing operations accurately and safely.
DO nOt use under wet conditions or in the presence of flammable liquids or gases.
This thickness planer is a professional power tool.
DO nOt let children come into contact with the tool. Supervision is required when
inexperienced operators use this tool.
• Young children and the infirm. This appliance is not intended for use by young children
or infirm persons without supervision.
• This product is not intended for use by persons (including children) suffering from
diminished physical, sensory or mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their safety. Children should never
be left alone with this product.

WARNING: Do not use the machine for other purposes than intended.

ASSEMBLY AND ADJUSTMENTS


WARNING: To reduce the risk of serious personal injury, turn tool off and
disconnect tool from power source before making any adjustments or removing/
installing attachments or accessories. An accidental start-up can cause injury.
Bench Mounting (Fig. B)
• Holes 6 are provided in all four feet to facilitate bench mounting. Two different sized
holes are provided to accommodate different sizes of bolts. Use either hole; it is not
necessary to use both. Always mount your machine firmly to prevent movement.
To enhance portability, the tool can be mounted to a piece of 12.5 mm or thicker
plywood which can then be clamped to your work support or moved to other job sites
and reclamped.
• When mounting your machine to a piece of plywood, make sure that the mounting
screws do not protrude from the bottom of the wood. The plywood must sit flush on the
work support.
• To prevent binding and inaccuracy, be sure the mounting surface is not warped or
otherwise uneven.

WARNING: The machine must be level and stable at all times.
Table Extensions (Fig. C1, C2)
1. Fold down the table extensions 5 and
2. Both tables must be level with the main table.
3. To check, turn the depth adjustment handle
a. Place a level over the table extensions and the main table
16
b. Press the edge of the table extensions down to remove any play.
4. If adjustment is required, proceed as follows: slacken the nuts
until the tables are level (Fig. C2).
Depth Adjustment (Fig. A2, D1–D4)
Your DW733 is equipped with a high precision depth adjustment system including a depth
adjustment scale 8 (Fig. D3), a material removal scale
stop (Fig. A2).
14
1. Unlock the head lock lever 2 (Fig. D3) by pulling it up.
2. Pull the depth adjustment 3 handle up (Fig. D1). One turn corresponds to a change in
cutting depth of approx. 1.5 mm.
- Turn clockwise to decrease the cutting depth.
- Turn counterclockwise to increase the cutting depth (Fig. D2).
3. Read the finished thickness of your workpiece on the depth adjustment scale
4. Make sure the material is under the material removal gauge
wood being removed on the material removal scale
5. Lock the head lock lever 2 (Fig. D3).
Fine Adjustment (Fig. D2)
Fine adjustments are ideal for shaving small amounts from planed material. For example, if
your planed workpiece is 77.5 mm and should be 76.0 mm, proceed as follows:
1. Turn the circular label until the 0 mark aligns with the arrow
21
other adjustments.
2. Turn the depth adjustment handle 3
the arrow.
3. Plane your workpiece. The final thickness is now 76.0 mm.
16
10 (Fig. C1).
3 all the way up.
.
17
and adjust the bolts
18
9 (Fig. D4), a fine adjuster and a depth
8
20 . Read the amount of
9 (Fig. D4).
. Do not make any
22
clockwise until the 1.5 mm mark aligns with
Depth Stop (Fig. A2, D3, D5)
The depth stop 14 (Fig. A2) can be used for repetitive planing of preset depths. Stops are set
at 0, 6, 12 and 19 mm.
Use the 0 mm stop for cutting depths between 3.2 and 6 mm.
1. Turn the depth stop until the desired measurement is indicated.
2. Unlock the head lock lever
until it contacts the depth stop. Do not turn the handle any further.
Use the 19 mm stop for other thicknesses. This will not affect the other
depth stop settings.
1. Unlock the head lock lever
to raise the head fully.
2. Loosen the nut 23 and adjust the depth adjustment bolt
3. Turn the depth adjustment handle until it contacts the depth stop. Do not turn the handle
any further.
4. Plane your workpiece and check its thickness. Make additional adjustments if required.
Calibrating the Depth Adjustment Scale (Fig. D3)
The depth adjustment scale
check the scale for accuracy.
Plane a piece of wood, noting the measurement on the depth adjustment scale
If adjustment is required, proceed as follows:
1. Loosen the screws .
33
2. Adjust the prism until the indicator
3. Firmly tighten the screws
Consult your dealer for further information on the appropriate accessories. These include spare
blades (DE7330).
Changing Blades (Fig. A1, A2, E1–E5)
Your DW733 is equipped with a cutterhead which holds two blades.
WARNING: Sharp edges.
WARNING: The blades can be re-sharpened max. 3 mm down from their original size.
If the blade size has decreased by more than 3 mm, the blades have to be replaced. The
blades can be re-sharpened at 42°.
Removing the Blades (Fig. A1, A2, E1–E4)
1. Unlock the head lock lever
2. Adjust the depth of cut to approx. 75 mm.
3. Remove the two hex screws
tool tray (Fig. A2) to expose the blades.
12
4. Carefully rotate the cutterhead
5. Lock the head lock lever
6. Loosen the seven blade clamping screws (
7. Remove the blade from the cutterhead for re-sharpening or replacement.
8. Press the cutterhead locking lever
other blade can be removed.
Replacing the Blades (Fig. E2–E5)
1. Position the cutterhead
2. Place the blade in the cutterhead and ensure that the head of the height adjustment
screw 27 (Fig. E4) locates into the blade slot.
3. Loosen the seven screws (
19
bit to allow the blade to be adjusted for height.
4. Place the gauge (Fig. E4) on the cutterhead as close as possible to the height
32
adjustment screw 27 while still allowing movement of the hex key.
5. Turn one height adjustment screw
gauge (Fig. E5). Repeat the procedure with the other height adjustment screw. Check
32
to ensure the blade height is even. Repeat this procedure if needed.
6. Tighten the two end clamping screws
7. Remove the gauge and tighten the five middle clamping screws
8. Press the cutterhead locking lever
other blade can be replaced following the above procedure.
OPERATION
(Fig. D3).
Instructions for Use

WARNING: Always observe the safety instructions and applicable regulations.

WARNING: To reduce the risk of serious personal injury, turn tool off and
disconnect tool from power source before making any adjustments or removing/
installing attachments or accessories. An accidental start-up can cause injury.

WARNING: Make sure there is sufficient space for the workpiece at the outfeed side.
The attention of UK users is drawn to the "woodworking machines regulations 1974" and any
subsequent amendments.
Ensure the machine is placed to satisfy your ergonomic conditions in terms of table height
and stability. The machine site shall be chosen so that the operator has a good overview and
2 (Fig. D3) and turn the depth adjustment handle clockwise
2 and turn the depth adjustment handle
24 as required (Fig. D5).
8 is factory set. In the case of extended use, it is recommended to
34 matches the finished thickness of the workpiece.
.
33
2 (Fig. A1).
25 (Fig. E1) and carefully remove the dust adaptor
30 (Fig. E4) until the first blade becomes visible.
2 (Fig. A1).
26 , 28 ) (Fig. E2) using the wrench supplied.
(Fig. E3) and slowly rotate the cutterhead until the
29
30 as shown in Figure E4.
26 , 28 ) (Fig. E2) on the blade clamp against the blade a little
27 with the hex key until the blade tip touches the
28 (Fig. E2) to 8.0 Nm.
26
29 (Fig. E3) and slowly rotate the cutterhead until the
3 counterclockwise
8 .
13 and
(Fig. E2) to 8.0 Nm.
