WARNING:
Never operate the tool without the
guard firmly in place. The guard must always be on the
tool to protect the user! When the guard is fixed, never
attempt to remove or adjust the guard, if a replacement
is needed, it should be performed by a qualified service
technician!
1. Loosen and remove the two screws from the guard
(Fig. B).
2. Align the guard mounting holes with the assembly
holes and then lock the guard onto the shaft base
with the two screws, together with two spring
washers (Fig. C).
NOTICE:
Make sure the guard is fixed according to
Fig. B & C, any reverse fixing will cause great danger!
MOUNTING AND ADJUSTING THE FRONT-ASSIST
HANDLE
1. Loosen the locking pole in the front-assist handle
and remove the locking pole and wing nut form the
front-assist handle (Fig.D).
Fig. D parts description see below:
D-1 locking pole
D-2 Front-Assist Handle
2. Push the front-assist handle onto the shaft (Fig. E).
3. Insert the clamping block into the handle slot (Fig. F).
4. Mount the locking pole, and pre-tighten them with
the wing nut. Make sure that the front-assist handle
is upwards and points toward the top of the rear
handle (Fig. G).
5. Adjust the front-assist handle between the threshold
ring and the label to make sure your front arm is
straight when operating (Fig. H).
6. Lock the lever of the locking pole. (Fig. I).
NOTICE: The front-assist handle should be turned
upwards to point toward the top of the rear handle.
WARNING: Only fix the front-assist handle
between the threshold ring and the label on the shaft.
WARNING: The tool cannot be used without the
front-assist handle securely fixed.
MOUNTING THE SHOULDER STRAP
Depress the strap hook to open it and attach it onto
the shoulder-strap mount hanger (Fig. J).
10
56 VOLT LITHIUM-ION CORDLESS LINE TRIMMER — ST1530E
D-3 Clamping Block
D-4 Wing Nut
OPERATION
WARNING: Do not allow familiarity with this
product to make you careless. Remember that a
careless fraction of a second is sufficient to inflict
serious injury.
WARNING: Always wear safety goggles or safety
glasses with side shield, along with hearing protection.
Failure to do so could result in objects being thrown
into your eyes and other possible serious injuries.
WARNING: Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories
not recommended can result in serious personal injury.
WARNING: To prevent serious personal injury,
remove the battery pack from the tool before servicing,
cleaning, changing attachments or removing material
from the unit.
You may use this product for the purposes listed below:
Trimming: use for removing grass and weeds up against
walls, fences, trees and borders.
Cutting: use for cutting the grass that is difficult to reach
using a normal mower.
NOTICE:
The tool is to be used only for its prescribed
purpose. Any other use, for example edge trimming, is
deemed to be a case of misuse.
ATTACHING/DETACHING THE BATTERY PACK
Fully charge before first use
To Attach
Align the battery ribs with the mounting slots and press the
battery pack down until you hear a "click" (Fig. K).
To Detach
Depress the battery-release button and pull the battery
pack out as Fig. L shown.
Fig. L parts description see below:
L-1 Battery- Release button
HOLDING THE LINE TRIMMER
WARNING:
Dress properly to reduce the risk of
injury when operating this tool. Do not wear loose
clothing or jewelry. Wear eye and ear/hearing protection.
Wear heavy duty, long trousers, boots and gloves. Do not
wear short trousers, sandals or go barefoot.
