GENERAL DESCRIPTION

1. Power level switches
2. Control lamp
3. Thermostat knob
4. Cord storage space
5. Feet
TECHNICAL DATA
- power: 2000 W
- supply voltage: 230 V ~ 50 Hz
HOW TO USE THE APPLIANCE
Thanks to the application of modern technology (heating element – plate made with the use
of mica), thermal efficiency of the heater HM1300 is much higher than in the case of traditional
convection and oil heaters. The heater is also much more comfortable in use, and radiation
and convection heat transmission is user-friendly.
- After unpacking the appliance, make sure it has not been damaged during transport.
In case of any doubts, do not use the appliance until consulting a service centre.
- Install the feet (5) with the use of the included screws.
- Place the appliance on a flat, stable surface resistant to high temperatures.
- Turn the switche (1) to position "0".
- Connect the appliance to a power source with parameters in accordance with the
Instructions for Use.
- Indicator light will go on.
- Turn the appliance on by pressing the switch (1)
- The appliance starts to work after selecting the temperature of operation with the use of the
thermostat knob (3).
When used for the first time, the heating elements and insulation can emit characteristic smell.
It is a normal phenomenon.
Do not cover outlets when the appliance is in operation.
The appliance is equipped with thermal protection system which cuts off power supply in case
of overheating. In such a case, turn the switches (1) to position "0", remove the power cord from
the socket and eliminate the cause of overheating (e.g. covered outlet). Before turning the
appliance on again, wait until it cools down.
The appliance works in a vertical position only. It is equipped with protection system which cuts
off power supply in case of overturning.
INSTRUCTIONS FOR USE
7
HEATER HM1300
5
2
1
3
4
