Ambient temperature of vehicle and charger.
Charging times can be longer at temperatures at
the upper and lower extremes of the permitted
ambient temperature.
– Temperature of the high-voltage battery and
control unit
– Passenger compartment precooling/heating ac-
tivated
– Current-carrying capacity of the permanent con-
nection and vehicle plug
Information
The charging power is dependent on the power grid,
the type of domestic connection and the start-up
of other high-usage electrical loads. It is possible
that the full charging power will not be available.
Further information is available from your qualified
electrician. Porsche recommends an authorized Por-
sche dealer as they have trained technicians and the
necessary parts and tools.
Starting, pausing and stopping charg-
ing
Starting charging
Information
− Charging is controlled by the vehicle. The charg-
ing process can only be stopped at the vehicle.
− The charge status is shown on the display pro-
vided the charger is not in standby mode. In
standby mode, the display can be switched on
again by pressing the Power button
display itself. In standby mode, the device can be
switched on again by pressing the Power button
.
− A high-temperature switch-off feature prevents
overheating while charging.
1. Insert the plug into the electrical socket.
Power button lights up white.
Status LEDs light up white.
�� The display turns on.
2. Insert the vehicle plug in the vehicle charge port.
For information on connecting the vehicle cable
to the vehicle charge port:
g See Owner's Manual.
Power button lights up white.
Status LEDs pulsate white.
�� Following a successful self-test and when
the connection is established, the status
LEDs light up white.
3. Charging starts automatically.
Power button lights up white.
Status LEDs pulsate green.
4. After a few minutes, the display switches to
standby mode.
�� The vehicle is charging.
Pausing charging
Charging is controlled by the vehicle and may occa-
sionally be paused, e.g. in order to optimize power
consumption.
When charging is paused, this will be indicated on
the control unit:
or the Power button lights up white.
Status LEDs flash blue.
The display turns on.
The vehicle starts charging again automatically. The
charging process can be stopped at the vehicle.
Stopping charging
b Charging was completed successfully.
Power button lights up white.
Status LEDs light up green.
The display switches on and shows information
about the completed charging process. After a
few minutes, the charger switches to standby
mode.
1. Disconnect the vehicle plug from the vehicle
charge port.
2. Lay the cable, without twisting it, around the
Wall Charger Connect and hang up the plug in
the parking position after charging.
Information
Improper use, in the form of torsion/twisting of the
vehicle cable while stretching or pulling on it, is to be
avoided.
