Requirements and prerequisites

Symbol Meaning
Display information
about the current
charging process
Display charging history
Making settings
A software update is
available.

Operating options

Fig. 4 Operating options
Back
A
Up/Down
B
Activity
C
Details
D
12
Skip
E
Requirements and prerequi-
sites
General requirements
Before the Wall Charger Connect is installed, the
following requirements must be complied with and
checked.
The following are the minimum requirements that
must be fulfilled for the connection of the Wall
Charger Connect:
– The Wall Charger Connect may only be installed
by a qualified technician (electrician).
– Calculate the maximum electrical load of the in-
stallation in order to determine the maximum
current of the wall box.
–
Ensure that the voltage drop across the supply
cable is minimal.
–
Only use copper wires to connect the Wall
Charger Connect.
–
Ensure that all approvals for connection of the
Wall Charger Connect have been granted and
that the installation is being/has been approved
by a qualified electrician.
– Only use connectors and cables that comply with
the local regulations so that the Wall Charger
Connect can be operated constantly at 80 A.
–
Use fuses for the electrical connection. Install
the fuse and residual current device in accord-
ance with your charging current.
–
Have the local requirements clarified by a quali-
fied electrician and observe the applicable condi-
tions.
